Drive Axle Forklift

Drive Axle for Forklift - The piece of machinery which is elastically connected to the framework of the vehicle utilizing a lift mast is referred to as the lift truck drive axle. The lift mast attaches to the drive axle and could be inclined, by at least one tilting cylinder, round the drive axle's axial centerline. Forward bearing components combined with rear bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented transversely and horizontally in the vicinity of the back bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the vehicle framework and the lift mast in an articulated fashion. This allows the tilting cylinder to be oriented nearly parallel to a plane extending from the swiveling axis to the axial centerline.

Model H45, H35 and H40 forklifts, that are manufactured by Linde AG in Aschaffenburg, Germany, have a attached lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the frame of the lift truck using many different bearings. The drive axle consists of tubular axle body together with extension arms attached to it and extend rearwards. This particular type of drive axle is elastically affixed to the vehicle framework by rear bearing elements on the extension arms along with forward bearing tools situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the forklift from the other bearing device in its respective pair.

The braking and drive torques of the drive axle on tis particular unit of forklift are sustained by the extension arms through the rear bearing components on the frame. The forces generated by the load being carried and the lift mast are transmitted into the floor or road by the vehicle frame through the front bearing elements of the drive axle. It is important to be certain the parts of the drive axle are put together in a firm enough way to be able to maintain strength of the lift truck truck. The bearing elements can lessen minor road surface irregularities or bumps throughout travel to a limited extent and give a bit smoother operation.
